Description
- Direct replacement for existing fluorescent lamps.
- Works off existing ballast and sockets.
- No re-wiring of the existing fixture is needed.
- Produces a 4000K cool white color.
- 50,000-hour long life rating.
- Backed by a 5-year limited manufacturer warranty.
Type A - Plug and Play: Type A LED lamps are the perfect choice for quick and effortless installation. These lamps are designed to directly replace traditional lamps, eliminating the need for any rewiring. With Type A LED lamps, you can easily upgrade your lighting system without any hassle. Simply plug them in and enjoy enhanced lighting efficiency. It is important to verify ballast compatibility, please refer to any attached documentation or consult with a sales associate.
No Wiring Needed: This lamps name is a plug and play style lamp and does not require you to re-wire your fixture or change the sockets - if they are not burned out.
Specifications
| SKU | 28728 |
| Manufacturer | Keystone Technologies |
| Brand | Keystone |
| Manufacturer Part Number | KT-LED13.5T8-48GC-840-S /G3 |
| Model / Product Code | KT-LED13.5T8-48GC-840-S /G3 |
| UPC | 843654136387 |
| Light Technology | LED |
| Lamp Shape | T8 |
| Wattage | 13.5 W |
| Equivalent Wattage | 32 W |
| Replaces | F32T8 |
| Base Code | G13 |
| Base Type | Medium Bi-Pin |
| Voltage | Ballast Dependent |
| Operating Temperature | -4°F to 113°F (-20°C to 45°C) |
| Operation | UL Type A |
| Color Temperature | 4000K |
| CRI | 80+ |
| Lumens | 2200 |
| Lumens per Watt | 157 |
| Beam Angle | 180° |
| Life Hours | 50000 |
| Nominal Length | 4 ft. |
| Length | 47.15 in. |
| Diameter | 1 in. |
| Fixture Rating | Enclosed |
| Location Rating | Damp |
| Power Factor | >0.9 |
| THD | <20% |
| Wiring | No Rewiring Needed |
| Compatible Sockets | Existing |
| Material | Coated Glass |
| Lens | Frosted |
| Dimmable | No |
| Dimming Type | N/A |
| UL | Yes |
| ETL | No |
| NSF | Yes |
| RoHS | Yes |
| FCC | Yes |
| Energy Star | No |
| DLC | Yes |
| DLC ID | PLVKG143BGRN |
| Warranty | 5-Year |
Warranty Information
Keystone Technologies, LLC., P.O. Box 246, Ambler, PA 19002, (215) 283-2600 (hereinafter called "Keystone Technologies”) offers a Keystone Standard LED Lamp Warranty. Keystone Technologies warrants that the lamps below will be free of defects in material and workmanship and comply with their respective published specifications, from the date of installation, for the 5 years and subject to the terms and conditions herein.
This warranty applies only to lamps that are operated a maximum of 8,760 hours/year (equal to 24 hours/day, 365 days/year). If lamps fail to operate for the warranty period, Keystone will, at its sole discretion, provide a free replacement lamp (but no labor allowance) or issue a credit for future purchase. Lamp warranty does not apply to vapor-tight fixture applications, unless explicitly stated in a warranty supplement letter from Keystone Technologies
View AllClose
Additional Information
Lamp Shape: |
T8 |
Operation Type: |
Type A (Plug n Play) |
Wiring Method: |
No Rewiring Needed |
Wattage: |
13.5 W |
Length: |
47.15 in. |
Lumens: |
2200 |
Lumens per Watt: |
157 |
Life Hours: |
50000 |
CRI: |
80+ |
Color Temperature (CCT): |
4000K |
Voltage: |
Ballast Dependent |
Base Type: |
Medium Bi-Pin |
Dimmable: |
No |
Equivalent: |
32 W |
