Description
Our commercial LED floodlights are dependable, versatile, and convenient, too. Everything you need is packaged together: fixture, built-in photocell, and multiple mounts, so you won’t get caught short on the job. Everything you need is in the box, including fixture with Power and Color Select technology, multiple mounting options, and a built-in dusk-to-dawn photocell. Lower-powered models include a yoke and knuckle mount, and more powerful floodlights come with a slipfitter and trunnion mount. Either way, we’ve got you covered. Ensures that XFit General-Purpose Floodlights only turn on when darkness is detected. That helps the fixture last longer — and saves money over that long life. You can turn the photocell on or off with a simple dip switch.
Listings & Certifications
Warranty Information
View AllCloseAdditional Information
View AllCloseSpecifications
Manufacturer: |
Keystone Technologies |
Brand: |
Keystone |
MPN: |
KT-FLED75PS-R4A-UNV-8CSB-VDIM |
Model: |
KT-FLED75PS-R4A-UNV-8CSB-VDIM |
Wattage: |
45/60/75 Watt |
Metal Halide Equivalent: |
200-320 Watt |
Lumens: |
6,390-11,250 |
Efficacy: |
130-162 lumens / Watt |
Color Temperature (CCT): |
3000/4000/5000 Kelvin |
Life Rating: |
50,000 Hours |
CRI: |
80+ |
Beam: |
Flood |
Light Distribution: |
7H x 7V NEMA |
Voltage: |
120/208/240/277 |
Frequency: |
N/A |
Power Factor: |
>0.95 |
THD: |
<20% |
Surge Protection: |
2.5kV |
Dimmable: |
Yes, 0-10V |
NEMA Receptable: |
No |
Photocontrol: |
Integrated, On / Off. |
Motion Sensor: |
No |
Housing Material: |
Aluminum |
Finish: |
Bronze |
Lens Material: |
Glass |
IP Rating: |
IP65 |
Location Rating: |
Wet |
Mounting: |
Slipfitter & Trunnion |
Length: |
14.57 in. |
Width: |
10.53 in. |
Height: |
3.61 in. |
UL: |
Yes |
ETL: |
No |
RoHS: |
Yes |
Energy Star: |
No |
FCC: |
Yes |
Title 20: |
No |
Title 24: |
No |
DLC: |
Yes |
DLC ID: |
S-7YVFWN |
Warranty: |
5-Year Manufacturer |
